eSSL Face Recognition and RFID Time & Attendance Access Control System - KF 500

Brand:  eSSL Security
Product Code:  eSSL KF 500
Availability:  10
0 reviews  (0 reviews)   |   Write a review

Model: eSSL KF500

The eSSL KF500 is an advanced face recognition device used for time attendance and Access Control. The device is a has a full black body with a 2.8”-inch TFT Screen and a 4x4 keypad for PIN operation. The device has a face capacity of 800 and ID Card Capacity of 2,000. The device uses RS232/485, TCP/IP, USB-Host systems for communication. It is capable of handling Door Lock & Door Sensor for the Access Control Interface. The device supports Chip encryption for firmware protection as well.


  • Face capacity: Up to 800
  • ID Card Capacity: 10,000
  • Record Capacity: 100,000
  • Display: 2.8”-inch TFT Screen
  • Communication: TCP/IP, Rs485, USB-Host
  • Work Code, SMS, DST, Scheduled Bell
  • Self-Service Query, Automatic Status Switch, Photo ID,
  • T9 Input, Camera, 9 digit user ID
  • Built-In Battery, Multiple Verify Mode, External Bell
  • Access Control Interface for: Door Lock, Door Sensor, Exit Button, Alarm, Wiegand Signal Input/Output
  • Optional Functions: ID
  • Power supply: DC12V, 3A
  • Operating temp: 0°C - 45°C
  • Operating Humidity: 20% - 80%
  • Dimension(mm): 173.0 x 159.0 x 36.1 (LxHxD)
  • Net Weight: 475g


  • Chip encryption for Firmware Protection
  • Prevents duplicated face registration
  • Supports fake face detection function

Technical Sheet: eSSL KF 500
