EZVIZ CS-C3N-A0-3H2WFRL(4mm) Wifi Camera

Compression

Video Compression :- H.265, H.264

Video Bit Rate :- Ultra-HD; HD; Standard. Adaptive bit rate.

General

Power Supply :- DC 12V/1A

Night Vision Distance (Black/White Night Vision Mode) :- Max. 30 meters(98.43ft)

Audio Reception :- Max. 5m

IP Grade :- IP67

Operating Conditions :- -22°F to 140 °F (-30ºC ~ 60ºC ); Humidity 95% or less ( non-condensing)

Power Consumption :- Max. 7W

Dimensions :- 75.5mm × 75.5mm × 155mm(2.97〃 × 2.97〃 × 6.10〃)

Packaging Dimensions :- 227mm × 100mm× 92mm(8.94〃 × 3.94〃 × 3.62〃)

Net Weight :- 422g(0.93lbs)

Wi-Fi

Standard :- IEEE802.11b, 802.11g, 802.11n

Frequency Range :-  2.4GHz ~ 2.4835 GHz

Transmission Rate :- 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps

Security :- 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Channel Bandwidth:- Supports 20MHz


BLC :- Supports

Frame Rate:- Max: 30fps; Self-Adaptive during network transmission

Max. Resolution: 1920 × 1080

Interface

Storage:- Micro SD card slot (Max. 256G)

Wired network:- RJ45 × 1(10M/100M Adaptive Ethernet Port)

Network Functions

Smart Alarm:- AI Powered Human Detection

Wi-Fi Pairing:- AP Pairing

Protocol:- EZVIZ Cloud Proprietary Protocol

Interface Protocol:- EZVIZ Cloud Proprietary Protocol

Max. Bitrate :- 2Mbps

Camera

Lens :- 4mm@ F2.0, view angle:102°(Diagonal), 86° (Horizontal)

Lens Mount:- M12

Day & Night:- IR-Cut filter with auto-switching

DNR :- 3D DNR

WDR :- Digital WDR
